Atmosphere™ Remote Bluetooth™ Audio Input

A-BT
Availability: In stock
MSRP (USD): $252.99
  • Daisy Chainable
  • Plug & Play
  • Decora Wall Plate
  • High Priority Notification
  • Digital Audio Return
  • NFC Pairing
  • Locate Function
    DESCRIPTION

    The Atmosphere A-BT is a remote Bluetooth™ audio input (mono) to an Atmosphere AZM audio processor. This expansion allows the Bluetooth™ receiver to be optimally placed for wireless coverage. The AZM will automatically detect the A-BT and dynamically assign appropriate audio settings, such as makeup gain, EQ, and auto gain control, to that input. The stereo source audio is summed to a mono signal before being sent to the AZM.

    Each Atmosphere accessory is a plug-and-play, intelligent device, specifically designed to be approachable and intuitive. The Atmosphere accessory bus allows for up to 8 devices to be connected to a single accessory port, reliably sending audio and data over 1000ft per port. Up to 1x audio input accessory can be added to each accessory port.


    FEATURES
    • Local pair/unpair button
    • User defined broadcast name (SSID)
    • Mono summed audio within the accessory
    • Pairing indication on the front panel
    • NFC pairing
    • Digital audio return to host processor

    SUPPORT FILES
    Data Sheet
    AZM4 and AZM8 Data Sheet
    CAD Drawing
    Atmosphere Acc Wall Plate Drawings
    Quick Start Guide
    Atmosphere Quick Start Guide
    User Manual
    Atmosphere User Manual
