Surface Mount Clock / Speaker Enclosure Mounts 830-89A Baffle

SM194-89
Availability: In stock
Your price (USD): $77.99
  • BAA
  • TAA
    DESCRIPTION
    Use AtlasIED 194 Series protective enclosures for recessed or surface mounting of 830 Series clock/speaker baffles. The 194 Series models contain 12 triple-compound conduit knockouts (six on both top and bottom) to facilitate easy wiring; 195 Series has 12 knockouts (four on both top and bottom, two at each end). Enclosures are constructed of 20-gauge CRS and are heavily undercoated to prevent mechanical resonances. Units contain a compartment divider to separate high and low voltage wiring. Models for surface application include an (SM) prefix and are finished in textured white epoxy to match the clock/speaker baffle panel.

    FEATURES
    • All Models Include Provisions for Easy Installation of Standard 8" Loudspeakers.
    • Easy-to-Configure Standard Panels in Model NC850 Provide Custom Flexibility for Mounting Switches, Thermostat, and/or Lighting Controls.
    • Recessed and Surface Mounting Styles Meet Installation Requirements.
    • Reliable Design Installs Quickly in New or Retrofit Construction

    SPECIFICATIONS
    Height 14 1/8" (35.8775 cm)
    Width 26 5/8" (67.6275 cm)
    Depth 3" (7.62 cm)
    Shipping Weight 9.50 lbs (4.31 kgs)
    Mounts Baffle 830-89A
