Horn Speaker 30W 8Ω

AP-30
Availability: In stock
Your price (USD): $160.99
  • 4OHM8OHMCAPABLE
  • IP34
    DESCRIPTION

    The 8-ohm Model AP-30 is a double re-entrant speakers which deliver 30-watts of continuous power handling, superior intelligibility and unparalleled efficiency. The AP-30 Series operates within a nominal frequency response range of 300Hz - 12kHz and offers a sensitivity of 121dB at rated power to provide clear voice and signal communication.

    The trademarked squared-bell design signifies AtlasIED quality and reliability. The Omni-Purpose® mounting bracket (supplied on all models) achieves precise positioning in the vertical and horizontal planes with a single adjustment and includes provisions for speaker installation on conventional surfaces as well as for strap mounting on I-beams or pillars. AP Series speakers are U.S. made to assure superior service reliability. Weather-resistant construction is metal and matching ABS plastic with metal components finished in grey epoxy.

    Learn more about the importance of protecting paging horns from low frequency damage and view the TSD-HF11 unit designed specifically to protect horns from low frequency damage.




    FEATURES
    • Environment Resistant for Outdoor and Indoor Use
    • Grey Finish
    • High-Efficiency Driver with Proven Performance Reliability
    • Omni-Purpose™ Bracket for Precise Positioning
    • Superior Intelligibility for Voice and Tone Signaling
    • World Recognized for Quality and Dependability

    SPECIFICATIONS
    Frequency Response 300Hz - 12kHz
    Sensitivity 108dB
    Dispersion 60°
    Power Rating 30 Watts
    Operating Temperature Range -40 to 70C
    Height 11" (27.94 cm)
    Width 10" (25.4 cm)
    Depth 10 1/2" (26.67 cm)
    Shipping Weight 6.00 lbs (2.72 kgs)

    SUPPORT FILES
    IN8244600
    Data Sheet
    ATS003854_AP-30_Series_Datasheet
    Revit Drawing
    AP-30 Revit Drawing
    Common Loud Speaker Format
    Atlas Sound AP-30T CLF2
    EASE File
    Atlas AP-30T EASE Data
