Caster Kit for 25 inch Deep 200 & 500 Series Racks

RCK-25
  • TAA
  • BAA
    This caster kit is comprised of four, non-locking, 2 5/8" Dia. casters, and two, easy-to-install, mounting/support brackets. This Model accommodates the 25.5" deep 200/500 Series cabinets.

    The heavy-duty, 14-gauge CRS mounting/support brackets are 4" wide and are designed to be affixed beneath the cabinet's bottom panel for front-to-back reinforcement. Brackets are .075" thick and feature two 1/2" downward flange on the inner edge, which provides additional structural support to the cabinet bottom.

    The zinc-plated swivel casters, which have an overall height of 3.75", feature 2 5/8" hard rubber tread wheels. Supports a load capacity of up to 1000 lbs.

    Brackets and casters mount directly to cabinets using supplied hardware. When in place, increases the cabinet's overall height by 1.75". Brackets are finished in black.
    FEATURES
    1000 Lb. Load Capacity Allows Maximum Equipment Installation
    Caster Kits Allow Racks to be Ganged Together
    Heavy-Duty Casters Enable "Easy-Roll" Movement
    Provide Mobility for Atlas Sound 19" Wide x 25 1/2" Deep Cabinets
    SPECIFICATIONS
    Height 3 3/4" (9.525 cm)
    Width 4" (10.16 cm)
    Mounts 25" Deep 200 & 500 Series
    Shipping Weight 13.75 lbs (6.24 kgs)
    SUPPORT FILES
    Data Sheet
    ATS004106 19%22 Wide Cabinets Accessories Datasheet RevA (1 page)
    Installation Sheet
    ATS004374_RCK-18-25-30_Install_Sheet (1 page)
